* Please visit the product pages on our website for the most up-to-date product information

JACKS & PLUGS

66

Jack Series

Ordering Information

Part No.

Conductors

Typical

Description

Mating Plug

Notes

Littel Phone Jacks

11

12A

12B

14B

2

2

3

3

single open

single closed

double open

double closed

280

280

297

297

Hi-D Jacks

111

112B

2

3

single open

double open

280

297

113BPC1M

114B

114BPC

114BPCS

114BPC1M

3

3

3

3

3

tip closed, ring open

(common to sleeve)

double closed

double closed

double closed

double closed

297 or

482NC

297

297

297

297 or

PC terms, accepts Littel

and Mil-type plugs

PC terms

Springlock PC terms

PC terms, accepts Littel and

482NC

Mil-type plugs, metric thread

Z15J

2

single open

187B

15A rated

Right Angle PC Mount 1/4" Jacks

RA49B11

RN112APC

RA49C14B

2

2

3

single open

single closed

double closed

280

280

297

1/4" Extension Jacks

80

88

120

121

131

133

2

2

2

2

3

3

single open

single open

single open

single open

double open

double open

280

280

280

280

297

298

Screw terms, black handle

Solder terms, black handle

Screw terms, shielded handle

Solder terms, shielded handle

Solder terms, shielded handle

Solder terms, shielded handle,

locking

830

128

1238

3

2

3

double open

single open

double open

297

280

297

Screw terms, black handle

Solder terms, shielded handle

Solder terms, shielded handle

See Pages 72–74 for Mechanical Drawings
